    AiSi Forged Metal Stainless Steel Equal Angle Architectural For Bridges Power

    Ask Lasest Price
    Brand Name : Tisco
    Model Number : Stainless Steel Angle
    Certification : ISO/ TUV/ SGS /BV and so on
    Price : Negotiated
    Payment Terms : L/C, T/T
    Supply Ability : 1000Ton/Month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    AiSi Forged Metal Stainless Steel Equal Angle Architectural For Bridges Power

    Stainless Steel Angle For Bridges / Power Transmission Towers


    ITEM
    Stainless Steel Bars/Channel/Angle/Round Bar/Hexagonal Bar
    Size
    Thickness:0.3-50mm; Length:2m,3m,5m,6m,9m,10m,12m or customized
    Tolerance
    Weight tolarance: -4% TO -6%;Width +/-0.8mm;Thickness +/-0.4mm;Length:+/-4-12mm
    Equal Angle
    Type: 2#-20#;Size: 20-200mm;Thickness: 3.0-24mm; Weight: 0.597-71.168kg/m
    Unequal
    Angle
    Type: 2.5*1.6-20*12.5#;Size:25*16-200*125mm;Long Side: 25-200mm
    Short Side: 16-125mm;Thickness: 3.0-18mm;Weight: 1.687-43.588kg/m
    Material
    201.202.301.302.304.304L.310S.316.316L.321.347,329,309S.2205.
    2507.2520.430.410.440.904Lect Or Customized
    Standard
    GB, AISI, ASTM, ASME, EN, BS, DIN, JIS
    Surface
    Mill finish. Galvanized.Forged.Hot Rolled.Cold Drawn.Peeled or customized
    Trade Term
    FOB CIF CFR CNF EXW
    Application
    Widely used in a variety of architectural and enginee
    ring structures,such as
    a.) beams, bridges, ship;
    b.) transmission tower, reaction tower;
    c.) lifting transportation machinery;
    d.) industrial furnace;
    e.)container frame, warehouse goods shelves, etc
    Package
    Standard export sea-worthy packing or customized
    Lead Time
    3-15 days after deposit
    Payment
    TT/LC

    GradeCSiMnPSNiCrMo
    201≤0.15≤0.755.5-7.5≤0.06≤ 0.033.5-5.516.0-18.0-
    301≤0.15≤1.0≤2.0≤0.045≤ 0.036.0-8.016.0-18.0-
    304≤0.08≤1.0≤2.0≤0.045≤ 0.038.0-13.018.0-20.0-
    304L≤0.03≤1.0≤2.0≤0.035≤ 0.039.0-13.018.0-20.0-
    309S≤0.08≤0.75≤2.0≤0.045≤ 0.0312.0-15.022.0-24.0-
    310S≤0.08≤1.0≤2.0≤0.045≤ 0.0319.0-22.024.0-26.0-
    314≤0.25≤1.5-3.0≤2.0≤0.045≤ 0.0319.0-22.023.0-26.0
    316≤0.08≤1.0≤2.0≤0.045≤ 0.0310.0-14.016.0-18.02.0-3.0
    316L≤0.03≤1.0≤2.0≤0.045≤ 0.0310.0-15.016.0-18.02.0-3.0
    321≤0.08≤1.0≤2.0≤0.035≤ 0.039.01317.0-19.0-
    347≤0.08≤0.75≤2.0≤0.045≤ 0.039.0-13.017.0-19.0
    410≤0.15≤1.0≤1.0≤0.035≤ 0.03-11.5-13.5-
    420≤0.16-0.25≤1.0≤1.0≤0.040≤ 0.03-12.0-14.0-
    430≤0.12≤0.75≤1.0≤0.040≤ 0.03≤0.6016.0-18.0-
    904L≤0.02≤1.0≤2.0≤0.045≤ 0.0323.0-28.019.0-23.0-

    Equal angle(A*T)
    Size (mm)Theoretical weight (kg/m)Size (mm)Theoretical weight (kg/m)Size (mm)Theoretical weight (kg/m)
    25*31.12475*77.976110*1422.809
    25*41.45975*89.03125*815.504
    30*31.37375*1011.089125*1019.133
    30*41.78680*67.376125*1222.696
    40*3185280*78.525125*1426.193
    40*42.42280*89.658140*1021.488
    40*52.97680*1011.874140*1225.522
    50*43.05990*68.35140*142949
    50*53.7790*79658140*1635.393
    50*64.46590*810.946160-1024.729
    60*545290*1013.476160*1229.391
    60*65.4290*1215.94160*1433.987
    63*54822100*69366160*1638.518
    63*65.721100*710.83180*1233.159
    63*87.469100*812.276180*1438.518
    63*109.151100*1015.12180*1643.542
    70*55.397100*1220.611180*1848.634
    70*66.406100*1623.257200*1442.894
    70*77.398110*711.928200*1648.68
    70*88.373110*813.532200*1854.401
    75*55.818110*1016.69200-2060.056
    75*66.905110*1219.782

    Unequal angle(A*T)
    Size (mm)Theoretical weight (kg/m)Size (mm)Theoretical weight (kg/m)Size (mm)Theoretical weight (kg/m)
    25*16*30.91275*50*87.431125*80*711.066
    32*20*31.17175*50*109.098125*80*812.551
    32*20*41.52280*50*55.005125*80*1015.474
    40*25*31.48480*50*65.935125*80*1218.33
    40*25*41.93680*50*76.848140*90*8141
    45*28*31.68780*50%7.745140*90*1017.475
    45*28*42.20390*56*55.661140*90*1220.724
    50*32*31.90890*56*66.717140*90*1423.908
    50*32*42.49490*56*88779160*100*1019872
    56*36*32.153100*63*78.722160*100*1427.274
    56*36*42.818100*63*89878160*100*1630.853
    56*396*53.466100*63*1012.142180*110*1022273
    63*40*43.185100*80*68.35180*110*1226.464
    63*40*53.92100*80*79656180*110*1430589
    63*40*64.638100*80*810.946180*110*1634.649
    70*45*54.403100*80*1013.476200*125*1229.761
    70*45*65.218110*70*68.35200*125*1434.436
    70*45*76011110*70*79.656200*125*1639.045
    75*50*54.808110*70*810.946200*125*1843.588
    75*50*65.699110*70*1013.476

    AiSi Forged Metal Stainless Steel Equal Angle Architectural For Bridges PowerAiSi Forged Metal Stainless Steel Equal Angle Architectural For Bridges PowerAiSi Forged Metal Stainless Steel Equal Angle Architectural For Bridges Power


    Delivery



    FAQ


    Q:Can you send samples?
    A:Of course, we can send samples to all parts of the world, our samples are free, but customers need to bear the courier costs.
    Q:What product information do I need to provide?
    A:You need to provide the grade, width, thickness, coating and the number of tons you need to purchase.
    Q:What are the shipping ports?
    A:Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can choose other ports according to your needs.
    Q:About product prices?
    A:Prices vary from period to period due to cyclical changes in the price of raw materials.
    Q:What are the certifications for your products?
    A:We have ISO 9001, SGS, EWC and other certifications.
    Q:Can I go to your factory to visit?
    A:Of course, we welcome customers from all over the world to visit our factory. However, some of the plants are not open to the public.
    Q:Does the product have quality inspection before loading?
    A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.
    Q:How to pack the products?
    A:The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It can effectively protect products from corrosion during ocean transportation.
    Q:What is your working time?
    A:In general, our online service time is Beijing time: 8:00-22:00, after 22:00, we will reply to your inquiry during the next
    working day.
